Features:
- CB & 10m Mobile antenna
- Tunable from 27 to 28.5 MHz
- 17/7 PH tapered stainless steel whip
- 180° inclination and adjustable whip, detachable for car-wash
- Suitable for magnetic mount
Electrical Data:
- Type: base loaded
- Frequency range: 27 ... 28.5 MHz
- Impedance: 50 ohm
- Bandwidth 1850 KHz /170 channels/
- Max. power: 35 Watts (CW) continuous, 250 Watts (CW) short time
- Standard mount : "N"
- Cable lenght / Type : 4 m / RG 58
Mechanical Data:
- Materials: Brass, Copper, Nylon, Stainless Steel
- Height (approx.): 1400 mm
- Weight (approx.): 480 gr
- Mounting hole: 12.5 mm.
Included are:
Antenna 1pcs.
base with 4m cable RG-58
Connector PL259 is not included
